Settings File
Warning
Deprecated — This documentation is no longer maintained here. The settings schema and its documentation have moved to the scanoss/schema repository. Please refer to the interactive docs or the canonical JSON Schema for the latest version.
SCANOSS provides a settings file to customize the scanning process. The settings file is a JSON file that contains project information and BOM (Bill of Materials) rules. It allows you to include, remove, or replace components in the BOM before and after scanning.
The schema is available to download here
Schema Overview
The settings file consists of two main sections:
Project Information
The self section contains basic information about your project:
{
"self": {
"name": "my-project",
"license": "MIT",
"description": "Project description"
}
}
Settings
The settings object allows you to configure various aspects of the scanning process. Currently, it provides control over which files should be skipped during scanning through the skip property.
Skip Configuration
The skip object lets you define rules for excluding files from being scanned or fingerprinted. This can be useful for improving scan performance and avoiding unnecessary processing of certain files.
Properties
skip.patterns.scanning
A list of patterns that determine which files should be skipped during scanning. The patterns follow the same format as .gitignore files. For more information, see the gitignore patterns documentation.
- Type:
Array of strings
- Required:
No
- Example:
{ "settings": { "skip": { "patterns": { "scanning": [ "*.log", "!important.log", "temp/", "debug[0-9]*.txt", "src/client/specific-file.js", "src/nested/folder/" ] } } } }
skip.patterns.fingerprinting
A list of patterns that determine which files should be skipped during fingerprinting. The patterns follow the same format as .gitignore files. For more information, see the gitignore patterns documentation.
- Type:
Array of strings
- Required:
No
- Example:
{ "settings": { "skip": { "patterns": { "fingerprinting": [ "*.log", "!important.log", "temp/", "debug[0-9]*.txt", "src/client/specific-file.js", "src/nested/folder/" ] } } } }
skip.sizes.scanning
Rules for skipping files based on their size during scanning.
- Type:
Object
- Required:
No
- Properties:
patterns(array of strings): List of glob patterns to apply the min/max size rulemin(integer): Minimum file size in bytesmax(integer): Maximum file size in bytes (Required)
- Example:
{ "settings": { "skip": { "sizes": { "scanning": [ { "patterns": [ "*.log", "!important.log", "temp/", "debug[0-9]*.txt", "src/client/specific-file.js", "src/nested/folder/" ], "min": 100, "max": 1000000 } ] } } } }
skip.sizes.fingerprinting
Rules for skipping files based on their size during fingerprinting.
- Type:
Object
- Required:
No
- Properties:
patterns(array of strings): List of glob patterns to apply the min/max size rulemin(integer): Minimum file size in bytesmax(integer): Maximum file size in bytes (Required)
- Example:
{ "settings": { "skip": { "sizes": { "fingerprinting": [ { "patterns": [ "*.log", "!important.log", "temp/", "debug[0-9]*.txt", "src/client/specific-file.js", "src/nested/folder/" ], "min": 100, "max": 1000000 } ] } } } }
Pattern Format Rules
Patterns are matched relative to the scan root directory
A trailing slash indicates a directory (e.g.,
path/matches only directories)An asterisk
*matches anything except a slashTwo asterisks
**match zero or more directories (e.g.,path/**/foldermatchespath/to,path/to/folder,path/to/folder/b)Range notations like
[0-9]match any character in the rangeQuestion mark
?matches any single character except a slash
Examples with Explanations
# Match all .txt files
*.txt
# Match all .log files except important.log
*.log
!important.log
# Match all files in the build directory
build/
# Match all .pdf files in docs directory and its subdirectories
docs/**/*.pdf
# Match files like test1.js, test2.js, etc.
test[0-9].js
Scan Tuning Parameters
The SCANOSS scan engine supports tuning parameters for snippet matching. These parameters allow you to fine-tune how the scanner identifies code snippets in your repository.
Parameter |
Type |
Default |
Description |
|---|---|---|---|
|
|
|
Minimum snippet hits required. |
|
|
|
Minimum snippet lines required. |
|
|
|
Enable/disable result ranking. |
|
|
|
Ranking threshold value ( |
|
|
|
Honour file extensions during matching. |
Example Configuration
Add the file_snippet section to your scanoss.json file:
{
"settings": {
"file_snippet": {
"min_snippet_hits": 3,
"min_snippet_lines": 5,
"ranking_enabled": true,
"ranking_threshold": 5,
"honour_file_exts": true
}
}
}
Complete Example
Here’s a comprehensive example combining pattern and size-based skipping:
{
"settings": {
"skip": {
"patterns": {
"scanning": [
"# Node.js dependencies",
"node_modules/",
"# Build outputs",
"dist/",
"build/"
],
"fingerprinting": [
"# Logs except important ones",
"*.log",
"!important.log",
"# Temporary files",
"temp/",
"*.tmp",
"# Debug files with numbers",
"debug[0-9]*.txt",
"# All test files in any directory",
"**/*test.js"
]
},
"sizes": {
"scanning": [
{
"patterns": [
"*.log",
"!important.log"
],
"min": 512,
"max": 5242880
}
],
"fingerprinting": [
{
"patterns": [
"temp/",
"*.tmp",
"debug[0-9]*.txt",
"src/client/specific-file.js",
"src/nested/folder/"
],
"min": 512,
"max": 5242880
}
]
}
}
}
}
BOM Rules
The bom section defines rules for modifying the BOM before and after scanning. It contains three main operations:
1. Include Rules
Rules for adding context when scanning. These rules will be sent to the SCANOSS API meaning they have more chance of being considered part of the resulting scan.
{
"bom": {
"include": [
{
"path": "/path/to/file",
"purl": "pkg:npm/vue@2.6.12",
"comment": "Optional comment"
}
]
}
}
2. Remove Rules
Rules for removing files from results after scanning. These rules will be applied to the results file after scanning. The post processing happens on the client side.
{
"bom": {
"remove": [
{
"path": "/path/to/file",
"purl": "pkg:npm/vue@2.6.12",
"comment": "Optional comment"
}
]
}
}
3. Replace Rules
Rules for replacing components after scanning. These rules will be applied to the results file after scanning. The post processing happens on the client side.
{
"bom": {
"replace": [
{
"path": "/path/to/file",
"purl": "pkg:npm/vue@2.6.12",
"replace_with": "pkg:npm/vue@2.6.14",
"license": "MIT",
"comment": "Optional comment"
}
]
}
}
Important Notes
Matching Rules
Full Match: Requires both PATH and PURL to match. It means the rule will be applied ONLY to the specific file with the matching PURL and PATH.
Partial Match: Matches based on either: - File path only (PURL is optional). It means the rule will be applied to all files with the matching path. - PURL only (PATH is optional). It means the rule will be applied to all files with the matching PURL.
File Paths
All paths should be specified relative to the scanned directory
Use forward slashes (
/) as path separators
Given the following example directory structure:
project/
├── src/
│ └── component.js
└── lib/
└── utils.py
- If the scanned directory is
/project/src, then: component.jsis a valid pathlib/utils.pyis an invalid path and will not match any files
- If the scanned directory is
- If the scanned directory is
/project, then: src/component.jsis a valid pathlib/utils.pyis a valid path
- If the scanned directory is
Package URLs (PURLs)
PURLs must follow the Package URL specification:
Format:
pkg:<type>/<namespace>/<name>@<version>Examples: -
pkg:npm/vue@2.6.12-pkg:golang/github.com/golang/go@1.17.3Must be valid and include all required components
Version is strongly recommended but optional
Example Configuration
Here’s a complete example showing all sections:
{
"self": {
"name": "example-project",
"license": "Apache-2.0",
"description": "Example project configuration"
},
"settings": {
"skip": {
"patterns": {
"scanning": [
"node_modules/",
"dist/",
"build/",
],
"fingerprinting": [
"*.log",
"!important.log",
"temp/",
"*.tmp",
"debug[0-9]*.txt",
"**/*test.js"
]
},
"sizes": {
"scanning": [
{
"patterns": [
"*.log",
"!important.log",
],
"min": 512,
"max": 5242880
}
],
"fingerprinting": [
{
"patterns": [
"temp/",
"debug[0-9]*.txt",
"src/client/specific-file.js",
"src/nested/folder/"
],
"min": 512,
"max": 5242880
}
]
}
},
"file_snippet": {
"min_snippet_hits": 3,
"min_snippet_lines": 5,
"ranking_enabled": true,
"ranking_threshold": 5,
"honour_file_exts": true
}
},
"bom": {
"include": [
{
"path": "src/lib/component.js",
"purl": "pkg:npm/lodash@4.17.21",
"comment": "Include lodash dependency"
}
],
"remove": [
{
"purl": "pkg:npm/deprecated-pkg@1.0.0",
"comment": "Remove deprecated package"
}
],
"replace": [
{
"path": "src/utils/helper.js",
"purl": "pkg:npm/old-lib@1.0.0",
"replace_with": "pkg:npm/new-lib@2.0.0",
"license": "MIT",
"comment": "Upgrade to newer version"
}
]
}
}
Usage
You can pass the settings file path as an argument to the CLI
$ scanoss-py scan . --settings /path/to/settings.json
If no settings file is provided, the default settings file will be used.
The default location for the settings file is scanoss.json in the current working directory.
If this file does not exist, settings will be omitted.
You can also skip the default settings file:
$ scanoss-py scan . --skip-settings-file
